效果图：
使用插件版本：
| 插件名称 | 版本 | 安装命令 |
| bpmn-js | 7.3.1 | npm install bpmn-js@^7.3.1 --save-D |
| bpmn-js-properties-panel | 0.37.2 | npm install bpmn-js-properties-panel@^0.37.2 --save-D |
| camunda-bpmn-moddle | 4.5.0 | npm install camunda-bpmn-moddle@^4.5.0 --save-D |
| didi | 5.0.0 | npm install didi@^5.0.0 |
组件封装完整代码：
<template>
<div>
<!-- 流程图容器 -->
<div class="container">
<!-- 创建一个canvas画布 npmn-js是通过canvas实现绘图的，并设置ref让vue获取到element -->
<div class="bpmn-canvas" ref="canvas"></div>
<!-- 工具栏显示的地方 -->
<div class="bpmn-js-properties-panel" id="js-properties-panel"></div>
<panel v-if="bpmnModeler" :modeler="bpmnModeler" />
<!-- 把操作按钮写在这里面 -->
<div class="toolbar">
<el-button type="primary" size="mini" @click="handleSave()">保存</el-button>
</div>
</div>
</div>
</template>
<script>
// bpmn 相关依赖
import BpmnModeler from "bpmn-js/lib/Modeler";
// 左侧自定义工具栏
import BpmData from "./BpmData";
// 右侧自定义属性面板
import panel from "./PropertyPanel-right.vue";
// BPMN国际化
import customTranslate from '@/util/bpmn/customTranslate';
// 自定义汉化模块
var customTranslateModule = {
translate: ['value', customTranslate]
}
import CustomPaletteProvider from './bpmn2'
export default {
name: "basic",
components: {
panel
},
data(){
return{
bpmnModeler: null,
element: null,
bpmData: new BpmData(),
}
},
created(){
},
mounted() {
const canvas = this.$refs.canvas;
// 生成实例
this.bpmnModeler = new BpmnModeler({
container: canvas,
// 加入工具栏支持
propertiesPanel: {
parent: "#js-properties-panel"
},
additionalModules: [
customTranslateModule,
{
// labelEditingProvider: ["value", ''], //禁用节点编辑
// contextPadProvider: ["value", ''], //禁用图形菜单
// bendpoints: ["value", {}], //禁用连线拖动
zoomScroll: ["value", ''], //禁用滚动
// moveCanvas: ['value', ''], //禁用拖动整个流程图
// move: ['value', ''], //禁用单个图形拖动
paletteProvider: ['type', CustomPaletteProvider], // 左侧工具栏
}
],
// moddleExtensions: {
// camunda: camundaModdleDescriptor
// }
});
// 新增流程定义
this.createNewDiagram();
},
methods:{
createNewDiagram() {
const bpmnXmlStr = `
<?xml version="1.0" encoding="UTF-8"?>
<bpmn2:definitions xmlns:bpmn2="http://www.omg.org/spec/BPMN/20100524/MODEL" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:bpmndi="http://www.omg.org/spec/BPMN/20100524/DI" xmlns:dc="http://www.omg.org/spec/DD/20100524/DC" xmlns:di="http://www.omg.org/spec/DD/20100524/DI" id="sample-diagram" targetNamespace="http://bpmn.io/schema/bpmn" xsi:schemaLocation="http://www.omg.org/spec/BPMN/20100524/MODEL BPMN20.xsd">
<bpmn2:process id="process1567044459787" name="流程1567044459787">
<bpmn2:documentation>描述</bpmn2:documentation>
<bpmn2:startEvent id="StartEvent_01ydzqe" name="开始">
<bpmn2:outgoing>SequenceFlow_1qw929z</bpmn2:outgoing>
</bpmn2:startEvent>
<bpmn2:sequenceFlow id="SequenceFlow_1qw929z" sourceRef="StartEvent_01ydzqe" targetRef="Task_1piqdk6" />
<bpmn2:userTask id="Task_1piqdk6" name="请假申请">
<bpmn2:incoming>SequenceFlow_1qw929z</bpmn2:incoming>
<bpmn2:outgoing>SequenceFlow_11h4o22</bpmn2:outgoing>
</bpmn2:userTask>
<bpmn2:exclusiveGateway id="ExclusiveGateway_0k39v3u">
<bpmn2:incoming>SequenceFlow_11h4o22</bpmn2:incoming>
<bpmn2:outgoing>SequenceFlow_1iu7pfe</bpmn2:outgoing>
<bpmn2:outgoing>SequenceFlow_04uqww2</bpmn2:outgoing>
</bpmn2:exclusiveGateway>
<bpmn2:sequenceFlow id="SequenceFlow_11h4o22" sourceRef="Task_1piqdk6" targetRef="ExclusiveGateway_0k39v3u" />
<bpmn2:sequenceFlow id="SequenceFlow_1iu7pfe" sourceRef="ExclusiveGateway_0k39v3u" targetRef="Task_10fqcwp" />
<bpmn2:userTask id="Task_10fqcwp" name="经理审批">
<bpmn2:incoming>SequenceFlow_1iu7pfe</bpmn2:incoming>
<bpmn2:outgoing>SequenceFlow_1xod8nh</bpmn2:outgoing>
</bpmn2:userTask>
<bpmn2:sequenceFlow id="SequenceFlow_04uqww2" sourceRef="ExclusiveGateway_0k39v3u" targetRef="Task_15n23yh" />
<bpmn2:userTask id="Task_15n23yh" name="总部审批">
<bpmn2:incoming>SequenceFlow_04uqww2</bpmn2:incoming>
<bpmn2:outgoing>SequenceFlow_0c8wrs4</bpmn2:outgoing>
</bpmn2:userTask>
<bpmn2:exclusiveGateway id="ExclusiveGateway_1sq33g6">
<bpmn2:incoming>SequenceFlow_0c8wrs4</bpmn2:incoming>
<bpmn2:incoming>SequenceFlow_1xod8nh</bpmn2:incoming>
<bpmn2:outgoing>SequenceFlow_0h8za82</bpmn2:outgoing>
</bpmn2:exclusiveGateway>
<bpmn2:sequenceFlow id="SequenceFlow_0c8wrs4" sourceRef="Task_15n23yh" targetRef="ExclusiveGateway_1sq33g6" />
<bpmn2:sequenceFlow id="SequenceFlow_1xod8nh" sourceRef="Task_10fqcwp" targetRef="ExclusiveGateway_1sq33g6" />
<bpmn2:endEvent id="EndEvent_0pnmjd3">
<bpmn2:incoming>SequenceFlow_0h8za82</bpmn2:incoming>
</bpmn2:endEvent>
<bpmn2:sequenceFlow id="SequenceFlow_0h8za82" sourceRef="ExclusiveGateway_1sq33g6" targetRef="EndEvent_0pnmjd3" />
</bpmn2:process>
<bpmndi:BPMNDiagram id="BPMNDiagram_1">
<bpmndi:BPMNPlane id="BPMNPlane_1" bpmnElement="process1567044459787">
<bpmndi:BPMNShape id="StartEvent_01ydzqe_di" bpmnElement="StartEvent_01ydzqe">
<dc:Bounds x="532" y="72" width="36" height="36" />
<bpmndi:BPMNLabel>
<dc:Bounds x="539" y="53" width="22" height="14" />
</bpmndi:BPMNLabel>
</bpmndi:BPMNShape>
<bpmndi:BPMNEdge id="SequenceFlow_1qw929z_di" bpmnElement="SequenceFlow_1qw929z">
<di:waypoint x="550" y="108" />
<di:waypoint x="550" y="150" />
</bpmndi:BPMNEdge>
<bpmndi:BPMNShape id="UserTask_1qxjy46_di" bpmnElement="Task_1piqdk6">
<dc:Bounds x="500" y="150" width="100" height="80" />
</bpmndi:BPMNShape>
<bpmndi:BPMNShape id="ExclusiveGateway_0k39v3u_di" bpmnElement="ExclusiveGateway_0k39v3u" isMarkerVisible="true">
<dc:Bounds x="525" y="275" width="50" height="50" />
</bpmndi:BPMNShape>
<bpmndi:BPMNEdge id="SequenceFlow_11h4o22_di" bpmnElement="SequenceFlow_11h4o22">
<di:waypoint x="550" y="230" />
<di:waypoint x="550" y="275" />
</bpmndi:BPMNEdge>
<bpmndi:BPMNEdge id="SequenceFlow_1iu7pfe_di" bpmnElement="SequenceFlow_1iu7pfe">
<di:waypoint x="575" y="300" />
<di:waypoint x="680" y="300" />
<di:waypoint x="680" y="380" />
</bpmndi:BPMNEdge>
<bpmndi:BPMNShape id="UserTask_18pwui1_di" bpmnElement="Task_10fqcwp">
<dc:Bounds x="630" y="380" width="100" height="80" />
</bpmndi:BPMNShape>
<bpmndi:BPMNEdge id="SequenceFlow_04uqww2_di" bpmnElement="SequenceFlow_04uqww2">
<di:waypoint x="525" y="300" />
<di:waypoint x="430" y="300" />
<di:waypoint x="430" y="380" />
</bpmndi:BPMNEdge>
<bpmndi:BPMNShape id="UserTask_1j0us24_di" bpmnElement="Task_15n23yh">
<dc:Bounds x="380" y="380" width="100" height="80" />
</bpmndi:BPMNShape>
<bpmndi:BPMNShape id="ExclusiveGateway_1sq33g6_di" bpmnElement="ExclusiveGateway_1sq33g6" isMarkerVisible="true">
<dc:Bounds x="525" y="515" width="50" height="50" />
</bpmndi:BPMNShape>
<bpmndi:BPMNEdge id="SequenceFlow_0c8wrs4_di" bpmnElement="SequenceFlow_0c8wrs4">
<di:waypoint x="430" y="460" />
<di:waypoint x="430" y="540" />
<di:waypoint x="525" y="540" />
</bpmndi:BPMNEdge>
<bpmndi:BPMNEdge id="SequenceFlow_1xod8nh_di" bpmnElement="SequenceFlow_1xod8nh">
<di:waypoint x="680" y="460" />
<di:waypoint x="680" y="540" />
<di:waypoint x="575" y="540" />
</bpmndi:BPMNEdge>
<bpmndi:BPMNShape id="EndEvent_0pnmjd3_di" bpmnElement="EndEvent_0pnmjd3">
<dc:Bounds x="532" y="602" width="36" height="36" />
</bpmndi:BPMNShape>
<bpmndi:BPMNEdge id="SequenceFlow_0h8za82_di" bpmnElement="SequenceFlow_0h8za82">
<di:waypoint x="550" y="565" />
<di:waypoint x="550" y="602" />
</bpmndi:BPMNEdge>
</bpmndi:BPMNPlane>
</bpmndi:BPMNDiagram>
</bpmn2:definitions>
`;
// 将字符串转换成图显示出来
this.bpmnModeler.importXML(bpmnXmlStr, err => {
if (err) {
console.error(err);
} else {
this.adjustPalette();
}
});
},
// 调整左侧工具栏排版
adjustPalette() {
try {
// 获取 bpmn 设计器实例
const canvas = this.$refs.canvas;
const djsPalette = canvas.children[0].children[1].children[4];
const djsPalStyle = {
width: "130px",
padding: "5px",
background: "white",
left: "20px",
borderRadius: 0
};
for (var key in djsPalStyle) {
djsPalette.style[key] = djsPalStyle[key];
}
const palette = djsPalette.children[0];
const allGroups = palette.children;
allGroups[0].style["display"] = "none";
// 修改控件样式
for (var gKey in allGroups) {
const group = allGroups[gKey];
for (var cKey in group.children) {
const control = group.children[cKey];
const controlStyle = {
display: "flex",
justifyContent: "flex-start",
alignItems: "center",
width: "100%",
padding: "5px"
};
if (control.className && control.dataset && control.className.indexOf("entry") !== -1) {
const controlProps = this.bpmData.getControl(control.dataset.action);
control.innerHTML = `<div style='font-size: 14px;font-weight:500;margin-left:15px;'>${
controlProps["title"]
}</div>`;
for (var csKey in controlStyle) {
control.style[csKey] = controlStyle[csKey];
}
}
}
}
} catch (e) {
console.log(e);
}
},
// 保存流程图
handleSave(){
// console.log(this.bpmnTemplate, "模板");
this.bpmnModeler.saveXML({ format: true }, (err, xml) => {
if (!err) {
console.log(xml);
}
});
},
},
}
</script>
<style lang="scss" scoped>
/*左边工具栏以及编辑节点的样式*/
@import "~bpmn-js/dist/assets/diagram-js.css";
@import "~bpmn-js/dist/assets/bpmn-font/css/bpmn.css";
@import "~bpmn-js/dist/assets/bpmn-font/css/bpmn-codes.css";
@import "~bpmn-js/dist/assets/bpmn-font/css/bpmn-embedded.css";
.container {
position: absolute;
background-color: #ffffff;
width: 97%;
height: 570px;
.bpmn-canvas {
width: 100%;
height: 570px;
}
.panel {
position: absolute;
right: 0;
top: 50px;
width: 300px;
}
.bjs-powered-by {
display: none;
}
.toolbar {
position: absolute;
top: 20px;
right: 350px;
a {
text-decoration: none;
margin: 5px;
color: #409eff;
}
}
}
</style>新建 bpmnData.js 文件设置左侧图形工具：
/**PaletteProvider
* 存储流程设计相关参数
*/
export default class BpmData {
constructor () {
this.controls = [] // 设计器控件
this.init()
}
init () {
this.controls = [
{ action: 'create.start-event', title: '开始' },
{ action: 'create.intermediate-event', title: '中间' },
{ action: 'create.end-event', title: '结束' },
{ action: 'create.exclusive-gateway', title: '条件' },
{ action: 'create.task', title: '任务' },
{ action: 'create.user-task', title: '用户任务' },
{ action: 'create.user-sign-task', title: '会签任务' },
{ action: 'create.subprocess-expanded', title: '子流程' },
{ action: 'create.data-object', title: '数据对象' },
{ action: 'create.data-store', title: '数据存储' },
{ action: 'create.participant-expanded', title: '扩展流程' },
{ action: 'create.group', title: '分组' }
]
}
// 获取控件配置信息
getControl (action) {
const result = this.controls.filter(item => item.action === action)
return result[0] || {}
}
}
新建 bpmn2.js 隐藏部分左侧不需要的工具图形：
import PaletteProvider from 'bpmn-js/lib/features/palette/PaletteProvider';
// 隐藏左侧工具栏部分的图形
export default class CustomPaletteProvider extends PaletteProvider {
constructor(palette, create, elementFactory, spaceTool, lassoTool, handTool, globalConnect, translate) {
super(palette, create, elementFactory, spaceTool, lassoTool, handTool, globalConnect, translate);
}
getPaletteEntries(element) {
const entries = super.getPaletteEntries(element);
// 隐藏指定类型的元素
delete entries['create.intermediate-event']; // 中间
delete entries['create.user-task']; // 用户任务
delete entries['create.user-sign-task']; // 会签任务
delete entries['create.subprocess-expanded'];// 子流程
delete entries['create.data-object'];// 数据对象
delete entries['create.data-store'];// 数据存储
delete entries['create.participant-expanded'];// 扩展流程
delete entries['create.group'];// 分组
return entries;
}
}
新建 PropertyPanel-right.vue 文件自定义右侧节点表单：
<template>
<div class="property-panel" ref="propertyPanel">
<el-form :inline="true" :model="form" label-width="100px" size="small">
<!-- <el-form-item label="节点ID">
<el-input v-model="form.id" disabled></el-input>
</el-form-item> -->
<el-form-item label="节点名称">
<el-input v-model="form.name" @input="nameChange" disabled style="width: 180px;"></el-input>
</el-form-item>
<el-form-item label="节点颜色">
<el-color-picker v-model="form.color" @active-change="colorChange"></el-color-picker>
</el-form-item>
<!-- 任务节点允许选择人员 -->
<el-form-item label="节点人员" v-if="userTask">
<el-select v-model="form.userType" placeholder="请选择" @change="typeChange" style="width: 180px;">
<el-option value="assignee" label="指定人员"></el-option>
<el-option value="candidateUsers" label="候选人员"></el-option>
<el-option value="candidateGroups" label="角色/岗位"></el-option>
</el-select>
</el-form-item>
<!-- 指定人员 -->
<el-form-item label="指定人员" v-if="userTask && form.userType === 'assignee'">
<el-select v-model="form.assignee" placeholder="请选择" key="1" @change="(value) => addUser({assignee: value})">
<el-option
v-for="item in users"
:key="item.value"
:label="item.label"
:value="item.value"
></el-option>
</el-select>
</el-form-item>
<!-- 候选人员 -->
<el-form-item label="候选人员" v-else-if="userTask && form.userType === 'candidateUsers'">
<el-select v-model="form.candidateUsers" placeholder="请选择" key="2" multiple
@change="(value) => addUser({candidateUsers: value.join(',') || value})">
<el-option
v-for="item in users"
:key="item.value"
:label="item.label"
:value="item.value"
></el-option>
</el-select>
</el-form-item>
<!-- 角色/岗位 -->
<el-form-item label="角色/岗位" v-else-if="userTask && form.userType === 'candidateGroups'">
<el-select v-model="form.candidateGroups" placeholder="请选择"
@change="(value) => addUser({candidateGroups: value})">
<el-option
v-for="item in roles"
:key="item.value"
:label="item.label"
:value="item.value"
></el-option>
</el-select>
</el-form-item>
<!-- 分支允许添加条件 -->
<el-form-item label="分支条件" v-if="sequenceFlow">
<el-select v-model="form.user" placeholder="请选择">
<el-option
v-for="item in users"
:key="item.value"
:label="item.label"
:value="item.value"
></el-option>
</el-select>
</el-form-item>
</el-form>
</div>
</template>
<script>
export default {
name: "PropertyPanel",
props: {
modeler: {
type: Object,
required: true
}
},
computed: {
userTask() {
if (!this.element) {
return;
}
return this.element.type === "bpmn:UserTask";
},
sequenceFlow() {
if (!this.element) {
return;
}
return this.element.type === "bpmn:SequenceFlow";
}
},
data() {
return {
form: {
id: "",
name: "",
color: null
},
element: {},
users: [
{ value: "zhangsan", label: "张三" },
{ value: "lisi", label: "李四" },
{ value: "wangwu", label: "王五" }
],
roles: [
{ value: "manager", label: "经理" },
{ value: "personnel", label: "人事" },
{ value: "charge", label: "主管" }
]
};
},
mounted() {
this.handleModeler();
},
methods: {
handleModeler() {
// 监听节点选择变化
this.modeler.on("selection.changed", e => {
const element = e.newSelection[0];
this.element = element;
console.log(this.element,'节点选择变化');
if (!element) return;
this.form = {
...element.businessObject,
...element.businessObject.$attrs
};
if (this.form.userType === "candidateUsers") {
this.form["candidateUsers"] =
this.form["candidateUsers"].split(",") || [];
}
});
// 监听节点属性变化
this.modeler.on("element.changed", e => {
const { element } = e;
if (!element) return;
// 新增节点需要更新回属性面板
if (element.id === this.form.id) {
this.form.name = element.businessObject.name;
this.form = { ...this.form };
}
});
},
// 属性面板名称，更新回流程节点
nameChange(name) {
const modeling = this.modeler.get("modeling");
modeling.updateLabel(this.element, name);
},
// 属性面板颜色，更新回流程节点
colorChange(color) {
const modeling = this.modeler.get("modeling");
modeling.setColor(this.element, {
fill: null,
stroke: color
});
modeling.updateProperties(this.element, { color: color });
},
// 任务节点配置人员
addUser(properties) {
this.updateProperties(
Object.assign(properties, {
userType: Object.keys(properties)[0]
})
);
},
// 切换人员类型
typeChange() {
const types = ["assignee", "candidateUsers", "candidateGroups"];
types.forEach(type => {
delete this.element.businessObject.$attrs[type];
delete this.form[type];
});
},
// 在这里我们封装一个通用的更新节点属性的方法
updateProperties(properties) {
const modeling = this.modeler.get("modeling");
modeling.updateProperties(this.element, properties);
}
}
};
</script>
<style lang="scss" scoped>
.property-panel {
position: absolute;
right: 0px;
top: 0px;
border-left: 1px solid #cccccc;
padding: 20px 0;
width: 300px;
height: 100%;
}
</style>在 util 文件夹下新建 customTranslate.js 文件，进行流程图语言汉化：
import translations from './language-zh';
export default function customTranslate(template, replacements) {
replacements = replacements || {};
// Translate
template = translations[template] || template;
// Replace
return template.replace(/{([^}]+)}/g, function(_, key) {
return replacements[key] || '{' + key + '}';
});
}
在 util 文件夹下新建 language-zh.js 文件，存放汉化语言包：
export default {
// Labels
'Activate the global connect tool' : '激活全局连接工具',
'Append {type}': '追加 {type}',
'Append EndEvent': '追加 结束事件 ',
'Append Task':'追加 任务',
'Append Gateway':'追加 网关',
'Append Intermediate/Boundary Event':'追加 中间/边界 事件',
'Add Lane above': '在上面添加道',
'Divide into two Lanes': '分割成两个道',
'Divide into three Lanes': '分割成三个道',
'Add Lane below': '在下面添加道',
'Append compensation activity': '追加补偿活动',
'Change type': '修改类型',
'Connect using Association': '使用关联连接',
'Connect using Sequence/MessageFlow or Association': '使用顺序/消息流或者关联连接',
'Connect using DataInputAssociation': '使用数据输入关联连接',
'Remove': '移除',
'Activate the hand tool': '激活抓手工具',
'Activate the lasso tool': '激活套索工具',
'Activate the create/remove space tool': '激活创建/删除空间工具',
'Create expanded SubProcess': '创建扩展子过程',
'Create IntermediateThrowEvent/BoundaryEvent' : '创建中间抛出事件/边界事件',
'Create Pool/Participant': '创建池/参与者',
'Parallel Multi Instance': '并行多重事件',
'Sequential Multi Instance': '时序多重事件',
'DataObjectReference':'数据对象参考',
'DataStoreReference':'数据存储参考',
'Loop': '循环',
'Ad-hoc': '即席',
'Create {type}': '创建 {type}',
'Create Task':'创建任务',
'Create StartEvent':'创建开始事件',
'Create EndEvent':'创建结束事件',
'Create Group':'创建组',
'Task': '任务',
'Send Task': '发送任务',
'Receive Task': '接收任务',
'User Task': '用户任务',
'Manual Task': '手工任务',
'Business Rule Task': '业务规则任务',
'Service Task': '服务任务',
'Script Task': '脚本任务',
'Call Activity': '调用活动',
'Sub Process (collapsed)': '子流程（折叠的）',
'Sub Process (expanded)': '子流程（展开的）',
'Start Event': '开始事件',
'StartEvent': '开始事件',
'Intermediate Throw Event': '中间事件',
'End Event': '结束事件',
'EndEvent': '结束事件',
'Create Gateway': '创建网关',
'GateWay':'网关',
'Create Intermediate/Boundary Event': '创建中间/边界事件',
'Message Start Event': '消息开始事件',
'Timer Start Event': '定时开始事件',
'Conditional Start Event': '条件开始事件',
'Signal Start Event': '信号开始事件',
'Error Start Event': '错误开始事件',
'Escalation Start Event': '升级开始事件',
'Compensation Start Event': '补偿开始事件',
'Message Start Event (non-interrupting)': '消息开始事件（非中断）',
'Timer Start Event (non-interrupting)': '定时开始事件（非中断）',
'Conditional Start Event (non-interrupting)': '条件开始事件（非中断）',
'Signal Start Event (non-interrupting)': '信号开始事件（非中断）',
'Escalation Start Event (non-interrupting)': '升级开始事件（非中断）',
'Message Intermediate Catch Event': '消息中间捕获事件',
'Message Intermediate Throw Event': '消息中间抛出事件',
'Timer Intermediate Catch Event': '定时中间捕获事件',
'Escalation Intermediate Throw Event': '升级中间抛出事件',
'Conditional Intermediate Catch Event': '条件中间捕获事件',
'Link Intermediate Catch Event': '链接中间捕获事件',
'Link Intermediate Throw Event': '链接中间抛出事件',
'Compensation Intermediate Throw Event': '补偿中间抛出事件',
'Signal Intermediate Catch Event': '信号中间捕获事件',
'Signal Intermediate Throw Event': '信号中间抛出事件',
'Message End Event': '消息结束事件',
'Escalation End Event': '定时结束事件',
'Error End Event': '错误结束事件',
'Cancel End Event': '取消结束事件',
'Compensation End Event': '补偿结束事件',
'Signal End Event': '信号结束事件',
'Terminate End Event': '终止结束事件',
'Message Boundary Event': '消息边界事件',
'Message Boundary Event (non-interrupting)': '消息边界事件（非中断）',
'Timer Boundary Event': '定时边界事件',
'Timer Boundary Event (non-interrupting)': '定时边界事件（非中断）',
'Escalation Boundary Event': '升级边界事件',
'Escalation Boundary Event (non-interrupting)': '升级边界事件（非中断）',
'Conditional Boundary Event': '条件边界事件',
'Conditional Boundary Event (non-interrupting)': '条件边界事件（非中断）',
'Error Boundary Event': '错误边界事件',
'Cancel Boundary Event': '取消边界事件',
'Signal Boundary Event': '信号边界事件',
'Signal Boundary Event (non-interrupting)': '信号边界事件（非中断）',
'Compensation Boundary Event': '补偿边界事件',
'Exclusive Gateway': '互斥网关',
'Parallel Gateway': '并行网关',
'Inclusive Gateway': '相容网关',
'Complex Gateway': '复杂网关',
'Event based Gateway': '事件网关',
'Transaction': '转运',
'Sub Process': '子流程',
'Event Sub Process': '事件子流程',
'Collapsed Pool': '折叠池',
'Expanded Pool': '展开池',
// Errors
'no parent for {element} in {parent}': '在{parent}里，{element}没有父类',
'no shape type specified': '没有指定的形状类型',
'flow elements must be children of pools/participants': '流元素必须是池/参与者的子类',
'out of bounds release': 'out of bounds release',
'more than {count} child lanes': '子道大于{count} ',
'element required': '元素不能为空',
'diagram not part of bpmn:Definitions': '流程图不符合bpmn规范',
'no diagram to display': '没有可展示的流程图',
'no process or collaboration to display': '没有可展示的流程/协作',
'element {element} referenced by {referenced}#{property} not yet drawn': '由{referenced}#{property}引用的{element}元素仍未绘制',
'already rendered {element}': '{element} 已被渲染',
'failed to import {element}': '导入{element}失败',
//属性面板的参数
'Id':'编号',
'Name':'名称',
'General':'常规',
'Details':'详情',
'Message Name':'消息名称',
'Message':'消息',
'Initiator':'创建者',
'Asynchronous Continuations':'持续异步',
'Asynchronous Before':'异步前',
'Asynchronous After':'异步后',
'Job Configuration':'工作配置',
'Exclusive':'排除',
'Job Priority':'工作优先级',
'Retry Time Cycle':'重试时间周期',
'Documentation':'文档',
'Element Documentation':'元素文档',
'History Configuration':'历史配置',
'History Time To Live':'历史的生存时间',
'Forms':'表单',
'Form Key':'表单key',
'Form Fields':'表单字段',
'Business Key':'业务key',
'Form Field':'表单字段',
'ID':'编号',
'Type':'类型',
'Label':'名称',
'Default Value':'默认值',
'Validation':'校验',
'Add Constraint':'添加约束',
'Config':'配置',
'Properties':'属性',
'Add Property':'添加属性',
'Value':'值',
'Add':'添加',
'Values':'值',
'Add Value':'添加值',
'Listeners':'监听器',
'Execution Listener':'执行监听',
'Event Type':'事件类型',
'Listener Type':'监听器类型',
'Java Class':'Java类',
'Expression':'表达式',
'Must provide a value':'必须提供一个值',
'Delegate Expression':'代理表达式',
'Script':'脚本',
'Script Format':'脚本格式',
'Script Type':'脚本类型',
'Inline Script':'内联脚本',
'External Script':'外部脚本',
'Resource':'资源',
'Field Injection':'字段注入',
'Extensions':'扩展',
'Input/Output':'输入/输出',
'Input Parameters':'输入参数',
'Output Parameters':'输出参数',
'Parameters':'参数',
'Output Parameter':'输出参数',
'Timer Definition Type':'定时器定义类型',
'Timer Definition':'定时器定义',
'Date':'日期',
'Duration':'持续',
'Cycle':'循环',
'Signal':'信号',
'Signal Name':'信号名称',
'Escalation':'升级',
'Error':'错误',
'Link Name':'链接名称',
'Condition':'条件名称',
'Variable Name':'变量名称',
'Variable Event':'变量事件',
'Specify more than one variable change event as a comma separated list.':'多个变量事件以逗号隔开',
'Wait for Completion':'等待完成',
'Activity Ref':'活动参考',
'Version Tag':'版本标签',
'Executable':'可执行文件',
'External Task Configuration':'扩展任务配置',
'Task Priority':'任务优先级',
'External':'外部',
'Connector':'连接器',
'Must configure Connector':'必须配置连接器',
'Connector Id':'连接器编号',
'Implementation':'实现方式',
'Field Injections':'字段注入',
'Fields':'字段',
'Result Variable':'结果变量',
'Topic':'主题',
'Configure Connector':'配置连接器',
'Input Parameter':'输入参数',
'Assignee':'代理人',
'Candidate Users':'候选用户',
'Candidate Groups':'候选组',
'Due Date':'到期时间',
'Follow Up Date':'跟踪日期',
'Priority':'优先级',
'The follow up date as an EL expression (e.g. ${someDate} or an ISO date (e.g. 2015-06-26T09:54:00)':'跟踪日期必须符合EL表达式，如： ${someDate} ,或者一个ISO标准日期，如：2015-06-26T09:54:00',
'The due date as an EL expression (e.g. ${someDate} or an ISO date (e.g. 2015-06-26T09:54:00)':'跟踪日期必须符合EL表达式，如： ${someDate} ,或者一个ISO标准日期，如：2015-06-26T09:54:00',
'Variables':'变量',
'Candidate Starter Configuration':'候选开始配置',
'Task Listener':'任务监听器',
'Candidate Starter Groups':'候选开始组',
'Candidate Starter Users':'候选开始用户',
'Tasklist Configuration':'任务列表配置',
'Startable':'启动',
'Specify more than one group as a comma separated list.':'指定多个组,用逗号分隔',
'Specify more than one user as a comma separated list.':'指定多个用户,用逗号分隔',
'This maps to the process definition key.':'这会映射为流程定义的键',
'CallActivity Type':'调用活动类型',
'Condition Type':'条件类型',
'Create UserTask':'创建用户任务',
'Create CallActivity':'创建调用活动',
'Called Element':'调用元素',
'Create DataObjectReference':'创建数据对象引用',
'Create DataStoreReference':'创建数据存储引用',
'Multi Instance':'多实例',
'Loop Cardinality':'实例数量',
'Collection':'任务参与人列表',
'Element Variable':'元素变量',
'Completion Condition':'完成条件'
};
最后页面引入即可使用：
<template>
<div>
<Bpmn></Bpmn>
</div>
</template>
import Bpmn from './components/bpmn.vue'
export default {
components: {
Bpmn
},
}至此完成！！！
测试有效！！！感谢支持！！！
